防爆救生圈自亮燈產品，如需要幫助請致電13337982885
一、概述
救生圈自亮浮燈采用高亮LED，該燈采用全塑外殼，自控開關以及全密封防水橡膠圈。特點是燈亮度高、光線輻射距離遠、節能，使用可靠壽命長，耐氣侯性好，無環境污染。DFQD-FB-A為防爆型。
燈罩采用聚碳酸脂注塑成形，結構件采用ABS注塑成形。以上材料具有重量輕，透光性好，有足夠的機械強度及抗沖擊強度，耐日光老化。
電源采用鋰電池壹節。安裝采用浮燈倒置卡具式。此卡具存取迅速，方便又可靠。當浮燈隨同救生圈入水后，燈罩漂浮在水面上并立即自動發光。因此，對夜間海上所有遇難人員，落水時無需操縱開關，救生圈燈能自動閃光示位，使遇難者及時得到救助。
二、主要技術參數：
型 號
技術參數 |
DFQD-FB-A |
|
發光強度 |
≥2cd |
|
工作時間 |
≥2小時 |
|
防爆等級 |
ExicIIAT4Gc |
|
工作電壓 |
3.6V |
|
燈泡額定參數 |
3.0V/0.9A |
|
儲存環境溫度 |
-30℃~ +65℃ |
|
工作環境溫度 |
-1℃~ +30℃ |
|
發光形式 |
閃光 |
|
閃光頻率 |
50~70次/分鐘 |
|
光色 |
白色 |
|
重量(含電池) |
550克 |
|
電池有效期 |
5年 |
三、注意事項
�。ㄒ唬┦褂脮r(shí)必須打開手動開關，圈燈必須倒懸裝備，即燈頭朝下。
�。ǘ┎灰S意擰卸燈罩，保證燈具在密封狀態。
（三）有效期一般以電池有效日期為準，然而，必須定期檢查電池質量，若發現燈光發紅或閃光頻率小于50次/分鐘或大于70次/分鐘，則證明電池電壓下降，此時客戶必須準備更換新。
�。ㄋ模┤艟褂锰刂茻襞�，客戶不能隨意更換或自配，燈泡壞了，應由工廠提供。
Instruction for Self-igniting buoy light
1、Summary
Lifebuoy light adopts highlight LED. DFQD-L-B lifebuoy light (flashing) is made of plastic shell, self-control switch and waterproof rubber ring. The product has the characteristics of high brightness, long lighting distance, economizing on energy, reliability for operating, long validity, good weather fastness and no environmental pollution，DFQD-FB-A Explosion-proof type.
The lampshade adopts the injection molding of polycarbonate . Structural parts adopt the injection molding of ABS . The above materials have the characteristics of lightweight, good transparency, adequate mechanical and anti-shock strength and the aging of daylight resistance.
Power supply uses one piece of lithium battery. Installation adopts a clip to clamp the buoy light upside down. The clip is swift in action, simple and reliable. When the buoy light enters into the water with the lifebuoy, the light shade can float on the surface of the water and give out light automatically. Therefore, to all people in danger on the sea at night, they needn't control the switch when they fall into the water. The lifebuoy light can give out flashing light automatically to indicate the site of the people, and the people in danger can be saved in time.
2、Main Technical Specifications
Model
Technical Parameters |
DFQD-C/
DFQD-FB-A |
|
Luminous Intensity |
≥2cd |
|
Time of power |
≥2h |
|
Explosion levels |
ExicIIAT4Gc |
|
Working Voltage |
3.6V |
|
Bulb Rating Parameter |
3.0V/0.9A |
|
Storage environment temperature |
-30℃~ +65℃ |
|
Working environment temperature |
-1℃~ +30℃ |
|
Lighting Form |
Flashing |
|
Flash Frequency |
50~70times/min |
|
Light color |
White |
|
Weight( including battery) |
550g |
|
Validity of battery |
5years |
3、Points for Attention:
(A) When using, please turn on the manual switch, the lifebuoy light should be equipped upside down.
(B)Do not twist off the light shade so as to ensure the tightness of the light.
(C)Validity of light is based on the validity of the cell to be used. However, the quality of the cell should be checked regularly. While checking, if the color of the light is found to be red or the flash frequency is slower than 50 times / min or faster than 70 times/min, it shows that the voltage of the light is not enough. At this time, the customer should replace it with a new light.
(D)The lifebuoy light is made of special bulb. The user should not change or use other bulbs. If the bulb is damaged, the user can apply for another one from our factory.
